Aluminum foil appearance inspection
Name | Parameter |
Detection speed: | ≤300m/min |
Detection width: | 800mm-1600mm |
Resolution: | Line scan: 0.03 (horizontal) * 0.03 (vertical) mm/pix; |
Detection accuracy: | Defect detection accuracy 0.05mm2 Pinhole detection accuracy: ≥0.03mm pinhole can be detected |
Overkill/missing rate: | Omission rate: 0%, overkill rate: ≤0.1% |
Inspection content: pits, black spots, black lines, oxidation spots, foreign matter, scratches, pinholes and other detectable defects with a gray scale difference of more than 20. | |
